Whissle Voice Agents API

The API is workspace-scoped: every request acts within one workspace, and usage is billed to that workspace's wallet. All requests go through the Whissle gateway:

https://aws-gateway-backend.whissle.ai/bot

All endpoints below are relative to the base URL (e.g. GET /api/agents → https://aws-gateway-backend.whissle.ai/bot/api/agents). Responses are JSON; timestamps are ISO-8601 UTC; IDs are UUIDs.

Moving off another voice-AI platform? Everything a conversational-AI agent does — prompt, greeting, voice, client & server tools, a knowledge base, an embeddable widget, and inbound/outbound phone — Whissle does too, plus its own speech recognition with emotion/intent metadata, real multilingual switching, and optional 3D avatars. You can recreate an agent in a few API calls; there is no separate runtime to stand up.

What maps to what

1. Get an API key

Create one in Settings → API keys and fund your wallet (sessions are metered, like the per-minute billing you're used to). See Authentication.

2. Re-create the agent

Port the prompt and first message straight across:

curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/agents \
  -H "Authorization: Bearer $WHISSLE_KEY" -H "Content-Type: application/json" \
  -d '{
    "name": "Acme Support",
    "system_prompt": "You are Acme'\''s support agent. Be concise and warm...",
    "greeting": "Hi, thanks for calling Acme — how can I help?",
    "agent_type": "customer_support",
    "language_mode": "auto"
  }'

The LLM is managed by Whissle (there is no per-agent model field) — for most teams that is one less key to hold. Everything else about the agent is a field you can set now or PATCH later.

3. Bring your tools & knowledge

Map each existing tool to a built-in tool, or register your own API as an HTTP tool — the secret lives in a stored credential, never in the tool spec:

# register your API as a tool, then attach it to the agent
curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/orgs/$ORG/tools \
  -H "Authorization: Bearer $WHISSLE_KEY" -H "Content-Type: application/json" \
  -d '{
    "name": "lookup_order", "kind": "http",
    "description": "Look up an order by its number.",
    "parameters": {"type":"object","properties":{"order_id":{"type":"string"}},"required":["order_id"]},
    "binding": {"url":"https://api.acme.com/orders/{order_id}","method":"GET"},
    "credential_id": "$CRED"
  }'

Bring your help-centre content with POST /api/agents/{id}/kb/upload (a file) or /kb/from-url (a page) — see Knowledge base. Retrieval is automatic in-call and returns citations.

4. Put it where your users are

• Website — in the agent’s Actions → Embed & SDK panel, list your site, turn the widget on, and paste the one-line iframe it gives you.
• Phone — connect Twilio and attach a number for inbound; place outbound with POST /api/calls/start.
• Your own app — start a WebRTC session and drive it with the Whissle JS SDK.

Already using just a TTS API? It's a smaller change — just point your text-to-speech calls at /api/models/tts and keep the rest of your stack.

Create a key in Settings → API keys (owner/admin). The secret is shown once — store it securely. Send it as a bearer token on every request:

curl https://aws-gateway-backend.whissle.ai/bot/api/agents \
  -H "Authorization: Bearer wsk_live_xxxxxxxxxxxxxxxxxxxx"

Keys are secret (wsk_…, server-side) — never expose them in a browser or commit them to source control. A key inherits the role of the member who created it and is scoped to a single workspace. Revoke a compromised key any time from the same settings page; it stops working immediately.

There are two key types. A secret key (wsk_…) is server-side and full-access — it authenticates the REST API in these docs. A publishable key (wpk_…) is domain-restricted and safe to ship to a browser (it backs the embed widget and @whissle/agents).

You can manage keys programmatically, scoped to your workspace at /api/orgs/{org_id}/api-keys:

# List your workspace keys (metadata only — never the secret). Scope: keys:read
curl https://aws-gateway-backend.whissle.ai/bot/api/orgs/{org_id}/api-keys \
  -H "Authorization: Bearer wsk_live_xxxxxxxxxxxxxxxxxxxx"

# Mint a publishable (wpk_) key for a browser/embed. Scope: keys:publish
curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/orgs/{org_id}/api-keys \
  -H "Authorization: Bearer wsk_live_xxxxxxxxxxxxxxxxxxxx" \
  -H "Content-Type: application/json" \
  -d '{"type": "publishable", "name": "website widget"}'
# → the wpk_ secret is returned ONCE; store it.

A wsk_ key can only mint publishable (wpk_) keys, and only within its own scopes — it can never mint another full-access secret key, so a leaked key can't escalate. Minting a new wsk_, revealing a key, and rotating or revoking one are dashboard-only (owner/admin, in Settings → API keys) — a compromised key must not be able to read, replace, or revoke its siblings.

Standard HTTP status codes:

• 200/201 — success
• 400 — invalid request body
• 401 — missing / invalid / revoked API key
• 403 — authenticated but not permitted (role/scope)
• 402 — insufficient wallet balance (top up to continue)
• 404 — resource not found (or not in your org)

Errors return { "detail": "message" }. Cross-tenant lookups return 404 (never 403) so resource existence isn't leaked.

An agent is a configured voice persona: prompt, greeting, voice, language, tools, avatar.

GET/api/agents

POST/api/agents

GET/api/agents/{id}

PATCH/api/agents/{id}

DELETE/api/agents/{id}

Create an agent:

curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/agents \
  -H "Authorization: Bearer $WHISSLE_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "name": "Support Agent",
    "system_prompt": "You are a friendly support agent for Acme.",
    "greeting": "Hi! Thanks for calling Acme — how can I help?",
    "agent_type": "customer_support"
  }'

Useful fields: voice, voice_gender, avatar_id (e.g. F1-HR), video_enabled, variables (template vars), tools, direction. Agent types: general, customer_support, debt_collection, appointment_scheduling, lead_qualification, survey_feedback, and more (see GET /api/agent-types).

Every voice session (phone, browser, or API-driven) is recorded as a call.

GET/api/calls

GET/api/calls/{id}

GET/api/calls/{id}/audio/url

List recent calls, filter by agent:

curl "https://aws-gateway-backend.whissle.ai/bot/api/calls?agent_id=$AGENT_ID" \
  -H "Authorization: Bearer $WHISSLE_KEY"

A call includes status, duration_sec, the full transcript (array of { role, content }), and analysis (emotion, intent, disposition, summary). /audio/url returns a signed link to the recording.

Real-time voice runs over WebRTC. Your client posts an SDP offer; the server returns an answer and a pc_id. The Whissle JS SDK handles the handshake for you, or post the offer yourself:

POST/api/offer?agent_id={id}

PATCH/api/offer

POST /api/offer?agent_id=<AGENT_ID>&avatar_id=F1-HR
Authorization: Bearer $WHISSLE_KEY
Content-Type: application/json

{ "sdp": "<offer SDP>", "type": "offer" }
# → { "sdp": "<answer SDP>", "pc_id": "..." }

Optional query params: avatar_id (3D avatar), video=1, customer_id (renders prompt templates against a customer), greeting=cached (instant pre-rendered greeting clip), and stt_provider/tts_provider overrides.

Use Whissle's models directly — no agent required. One API for language, speech-to-text, and text-to-speech, metered into your workspace wallet. Keys need the models:invoke scope (included by default).

POST/api/models/chat

POST/api/models/transcribe

POST/api/models/tts

LLM — chat completion:

curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/models/chat \
  -H "Authorization: Bearer $WHISSLE_KEY" -H "Content-Type: application/json" \
  -d '{
    "messages": [
      { "role": "system", "content": "You are concise." },
      { "role": "user", "content": "Summarize the Kubernetes control plane." }
    ],
    "max_tokens": 512,
    "fast": false
  }'
# → { "text": "...", "usage": { "input_tokens": 42, "output_tokens": 118 },
#     "cost_usd": "0.00002...", "latency_ms": 640 }

model is optional (a sensible default is used); set fast: true for the cheaper small-model tier.

Speech-to-Text — upload an audio file (multipart):

curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/models/transcribe \
  -H "Authorization: Bearer $WHISSLE_KEY" \
  -F "file=@call.wav" \
  -F "language=" -F "model=en-in-tech-misc" -F "diarize=false"
# → { "text": "...", "duration_seconds": 12.4, "cost_usd": "0.00124" }

Set diarize=true for speaker labels (returns a segments array, billed at the diarization rate).

Text-to-Speech — returns audio/mpeg bytes:

curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/models/tts \
  -H "Authorization: Bearer $WHISSLE_KEY" -H "Content-Type: application/json" \
  -d '{ "text": "Hello from Whissle." }' \
  --output hello.mp3
# response headers: X-Cost-USD, X-Characters

Rates (USD): LLM $0.05/$0.19 per 1M input/output tokens (fast $0.03/$0.12); STT $0.006/min ($0.009 with diarization); TTS $18 / 1M characters. See Pricing for the full table.

Customer records personalize an agent's prompt (name, due amount, language, …).

GET/api/customers

POST/api/customers

POST/api/customers/import

PATCH/api/customers/{id}

DELETE/api/customers/{id}

curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/customers \
  -H "Authorization: Bearer $WHISSLE_KEY" -H "Content-Type: application/json" \
  -d '{ "name": "Rahul Gupta", "phone_number": "+91...", "preferred_language": "hi-en" }'

Configure how a booking agent schedules — operating hours, days it won't book, and the connected calendar. The bookings themselves are created by the agent's book_appointment tool during a call or chat and land on your connected calendar; this API is the configuration around that. All endpoints are workspace-scoped (appointments:read / appointments:write).

GET/api/orgs/{org_id}/appointments

PATCH/api/orgs/{org_id}/appointments

GET/api/orgs/{org_id}/appointments/hours

PUT/api/orgs/{org_id}/appointments/hours

GET/api/orgs/{org_id}/appointments/blocked-dates

POST/api/orgs/{org_id}/appointments/blocked-dates

DELETE/api/orgs/{org_id}/appointments/blocked-dates/{blocked_id}

GET/api/orgs/{org_id}/appointments/calendar

# Set the agent's operating hours (Mon–Fri 9–17)
curl -X PUT https://aws-gateway-backend.whissle.ai/bot/api/orgs/$ORG/appointments/hours \
  -H "Authorization: Bearer $WHISSLE_KEY" -H "Content-Type: application/json" \
  -d '{ "hours": [ {"day": "mon", "open": "09:00", "close": "17:00"} ] }'

Connecting a calendar: Google Calendar, Calendly and Cal.com are connected from Settings → Appointments (an OAuth sign-in), not over the API — a leaked key must not be able to rewire where your bookings go. GET …/calendar reports the current connection.

Attach documents to an agent for grounded answers (RAG over your content).

GET/api/agents/{id}/kb

POST/api/agents/{id}/kb

POST/api/agents/{id}/kb/upload

POST/api/agents/{id}/kb/from-url

Add a snippet, upload a PDF/TXT, or ingest a URL; documents are chunked and embedded.

One unified history of everything an agent handled — phone calls, browser and embed voice, and text threads. Every item carries a kind discriminator (voice | text). (Distinct from starting a voice session above — this is the record of finished ones.)

GET/api/sessions

GET/api/sessions/{id}

GET/api/sessions/{id}/trace

List is newest-first and filterable: agent_id, kind (voice|text), limit (1–200), offset, and since. The /trace endpoint returns the per-turn timeline — which provider/model answered (and whether it failed over), every tool call with its args and citations, latency, token cost, and any action-integrity catches. Requires calls:read.

curl "https://aws-gateway-backend.whissle.ai/bot/api/sessions?kind=text&limit=20" \
  -H "Authorization: Bearer $WHISSLE_KEY"
# -> { "items": [ { "id": "...", "kind": "text", "agent_id": "...", ... } ],
#      "total": 137, "totals": { "voice": 41, "text": 96 } }

Give an agent a tool that calls your own HTTP API. A custom tool is defined once on the org and attached to any agent by name — the same tool can back many agents. (The agent also has built-in tools and, if you connect one, tools bridged from an MCP server.)

GET/api/orgs/{org}/tools

POST/api/orgs/{org}/tools

PUT/api/orgs/{org}/tools/{tool_id}

DELETE/api/orgs/{org}/tools/{tool_id}

POST/api/orgs/{org}/tools/{tool_id}/attach

parameters is a JSON Schema the model fills to call the tool; the request is made from our servers behind an SSRF guard. Listing needs tools:read; create/update/delete/attach need tools:write.

# 1. define the tool on the org
curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/orgs/$ORG/tools \
  -H "Authorization: Bearer $WHISSLE_KEY" -H "Content-Type: application/json" \
  -d '{ "name": "lookup_order", "description": "Look up an order by its id",
        "kind": "http",
        "parameters": { "type": "object",
          "properties": { "order_id": { "type": "string" } },
          "required": ["order_id"] },
        "binding": { "method": "GET", "url": "https://api.yourshop.com/orders/{order_id}" } }'

# 2. attach it to an agent
curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/orgs/$ORG/tools/$TOOL_ID/attach \
  -H "Authorization: Bearer $WHISSLE_KEY" -H "Content-Type: application/json" \
  -d '{ "agent_id": "$AGENT_ID" }'

Launch an outbound campaign — a batch of calls (or emails) an agent makes to your contacts, paced and compliance-gated. Every dial runs through the same rails as an agent-initiated call: do-not-call suppression, consent, per-recipient frequency caps, quiet-hours, and a wallet credit check — all fail-closed, so a campaign never dials a suppressed or unfunded contact.

POST/api/campaigns

GET/api/campaigns

GET/api/campaigns/{id}

POST/api/campaigns/{id}/{action}

Create takes { name, agent_id, … }. Key fields:calls_per_hour (1–1000, default 60) paces the dialer; customer_ids selects contacts (omit to target every contact scoped to the agent); window_start/window_end (0–23) bound the dial hours — pass both or neither (one alone reads as no window). For a program, a future start_at (ISO) and/or recurrence with a timezone makes it scheduled (the launcher enqueues when due); stop_on_dispositions halts a contact's follow-ups once an outcome is reached.channel defaults to voice; set email with email_subject/email_body for an email campaign. The create and read responses carry live progress (enqueued/sent/failed/…).

{action} is pause, resume, or cancel. Reading needs campaigns:read; creating and controlling need campaigns:write.

curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/campaigns \
  -H "Authorization: Bearer $WHISSLE_KEY" -H "Content-Type: application/json" \
  -d '{ "name": "March renewals", "agent_id": "$AGENT_ID",
        "calls_per_hour": 40, "window_start": 9, "window_end": 18, "timezone": "America/New_York" }'
# -> { "id": "...", "status": "running", "enqueued": 212, "progress": { ... } }

Two ways to give an agent capabilities beyond its built-in tools, both org-scoped:

Connectors — the credential vault

Store a per-org integration secret (an EHR/fhir endpoint, an SMTP mailbox, a Google Sheet, …), encrypted at rest — the agent uses it without ever seeing the secret. A credential is org-wide by default, or pass agent_idto scope it to one agent.

GET/api/orgs/{org}/credentials

POST/api/orgs/{org}/credentials

GET/api/orgs/{org}/credentials/{id}

PUT/api/orgs/{org}/credentials/{id}

DELETE/api/orgs/{org}/credentials/{id}

POST/api/orgs/{org}/credentials/{id}/test

Create takes { kind, name, data, agent_id? } — kindcategorizes the connector (e.g. fhir, smtp) and data holds the secret fields. /test verifies the connection before an agent relies on it. Reading needs connectors:read; writing and testing need connectors:write.

Integrations — connect an MCP server

Connect an external MCP server (from the curated catalog or a pasted URL) and its tools become tools your agents can call — one connection, the whole server's toolset.

GET/api/orgs/{org}/integrations/catalog

GET/api/orgs/{org}/integrations

GET/api/orgs/{org}/integrations/connected

POST/api/orgs/{org}/integrations

POST/api/orgs/{org}/integrations/{id}/connect

POST/api/orgs/{org}/integrations/{id}/oauth/start

Create takes { name, server_url, auth_mode } where auth_mode is none, bearer, apikey, or oauth (for bearer/apikey, include the token; for oauth, drive /oauth/start). /catalog lists the app-store cards; /connected lists what's live. Reading needs integrations:read; connecting needs integrations:write (owner/admin — a connected server acts on the org's identity).

curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/orgs/$ORG/integrations \
  -H "Authorization: Bearer $WHISSLE_KEY" -H "Content-Type: application/json" \
  -d '{ "name": "Airtable", "server_url": "https://mcp.example.com/airtable", "auth_mode": "bearer" }'

There are two key types. A secret key (wsk_…) is server-side and full-access — it authenticates the REST API in these docs. A publishable key (wpk_…) is domain-restricted and safe to ship to a browser (it backs the embed widget and @whissle/agents).

You can manage keys programmatically, scoped to your workspace at /api/orgs/{org_id}/api-keys:

# List your workspace keys (metadata only — never the secret). Scope: keys:read
curl https://aws-gateway-backend.whissle.ai/bot/api/orgs/{org_id}/api-keys \
  -H "Authorization: Bearer wsk_live_xxxxxxxxxxxxxxxxxxxx"

# Mint a publishable (wpk_) key for a browser/embed. Scope: keys:publish
curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/orgs/{org_id}/api-keys \
  -H "Authorization: Bearer wsk_live_xxxxxxxxxxxxxxxxxxxx" \
  -H "Content-Type: application/json" \
  -d '{"type": "publishable", "name": "website widget"}'
# → the wpk_ secret is returned ONCE; store it.

A wsk_ key can only mint publishable (wpk_) keys, and only within its own scopes — it can never mint another full-access secret key, so a leaked key can't escalate. Minting a new wsk_, revealing a key, and rotating or revoking one are dashboard-only (owner/admin, in Settings → API keys) — a compromised key must not be able to read, replace, or revoke its siblings.

Send SMS from your org's number and read the delivery, opt-out and consent records. These are org-scoped — {org} is your organization id (from whoami).

POST/api/orgs/{org}/sms/send

GET/api/orgs/{org}/sms/messages

GET/api/orgs/{org}/sms/opt-outs

DELETE/api/orgs/{org}/sms/opt-outs/{phone}

GET/api/orgs/{org}/sms/consents

send takes { to_number, body, agent_id? } and always routes through the same compliance rails as an agent-initiated message: opt-out suppression (a suppressed recipient returns 403), duplicate suppression, a per-recipient burst cap, a per-message wallet debit, and the delivery log — it never goes straight to the carrier. agent_id sends from the number assigned to that agent; omit it to use the org default. Sending spends credit. messages takes limit (1–500, default 100);consents takes limit (1–1000, default 200).

Reading (messages, opt-outs, consents) needs sms:read; sending and removing an opt-out need sms:write.

curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/orgs/$ORG/sms/send \
  -H "Authorization: Bearer $WHISSLE_KEY" -H "Content-Type: application/json" \
  -d '{ "to_number": "+15551234567", "body": "Your appointment is confirmed for Tue 3pm." }'
# -> { "sid": "SM...", "status": "queued", "to": "+15551234567" }

The org's Do-Not-Call list, calling rules, enforcement audit trail, and the data-erasure endpoint — the API behind every automated call and message. Org-scoped; {org} is your organization id.

GET/api/orgs/{org}/compliance/suppressions

POST/api/orgs/{org}/compliance/suppressions

DELETE/api/orgs/{org}/compliance/suppressions/{phone}

GET/api/orgs/{org}/compliance/settings

PUT/api/orgs/{org}/compliance/settings

GET/api/orgs/{org}/compliance/events

POST/api/orgs/{org}/compliance/erase

GET/api/orgs/{org}/compliance/readiness

suppressions is the Do-Not-Call list: POST a { phone_number, reason? } to block a number, DELETE to re-enable it. settings holds the calling rules — an org that has never configured anything gets safe defaults (consent + disclosure required), never permissive ones. events is the enforcement audit log: what the rules actually did, per call. erase deletes everything held about one person on request (GDPR/CCPA). readiness lists everything still standing between the org and safe autonomous calling.

Reading (suppressions, settings, events, readiness) needs compliance:read; changing anything (POST/PUT/DELETE/erase) needs compliance:write and an owner/admin role.

curl -X POST https://aws-gateway-backend.whissle.ai/bot/api/orgs/$ORG/compliance/suppressions \
  -H "Authorization: Bearer $WHISSLE_KEY" -H "Content-Type: application/json" \
  -d '{ "phone_number": "+15551234567", "reason": "customer requested no contact" }'
# -> 201 Created

Get notified when a call finishes. Each agent can carry a guaranteed completion webhook — the outcome dispatcher fires it for every completed call, with the same payload the LLM-invoked webhook tool sends.

It is an agent config field, not a separate endpoint — set completion_webhook on a PATCH /api/agents/{id}:

curl -X PATCH https://aws-gateway-backend.whissle.ai/bot/api/agents/$AGENT_ID \
  -H "Authorization: Bearer $WHISSLE_KEY" -H "Content-Type: application/json" \
  -d '{ "completion_webhook": {
          "url":     "https://your-app.example.com/whissle/call-finished",
          "secret":  "whsec_...",           // optional: HMAC-signs the request body
          "headers": { "X-Env": "prod" },   // optional: extra request headers
          "slim":    false                  // true = summary only, no transcript/recording
       } }'

The url is SSRF-validated when you set it — a private, loopback or metadata address is rejected with 422 at PATCH time, not at fire time. Send null or {} to clear it; setting it needs agents:write. The delivery carries the call's transcript, a signed recording_url, summary, disposition and structured result — the same object session history exposes. slim: true ships the summary only (no transcript or recording); an optional secret HMAC-signs the body so you can verify authenticity.

Voice agents are a flat $0.04 / minute, all-inclusive (STT + LLM + TTS + avatar) — across phone, browser, API, and embedded sessions, debited when a session finalizes. À-la-carte model calls (/api/models/*) are metered per unit at the rates in the Models section. Both draw down the same prepaid wallet.

If the balance is empty, session-start returns 402 Payment Required — top up in Settings → Billing & usage (Stripe). Every debit and top-up is recorded in the wallet ledger with a running balance.

Live today, no backend and no code beyond one <iframe>. In the agent’s Actions → Embed & SDK panel:

1. Add each website that may run the agent (one origin per line, e.g. https://acme.com).
2. Toggle Widget is live on.
3. Copy the snippet it reveals and paste it into your page:

<iframe src="https://whissle.ai/embed/<YOUR_EMBED_KEY>"
        style="width:400px;height:600px;border:0;border-radius:16px"
        allow="microphone; geolocation" title="AI agent"></iframe>

The embed key is public (it sits in your page source), so the allowed-sites list is the security boundary: the backend only mints a session token for an origin you listed, so no one else’s site can spend your balance. A text agent renders a chat box (no mic prompt); a voice agent asks for the microphone. Sessions bill to your workspace like any other.

Want to control the widget from your own UI instead of an iframe — custom button, your own layout, WebRTC in your app? Use the Whissle JS SDK (@whissle/agents) with a publishable key (wpk_…, domain-restricted, safe in a browser). A drop-in <script> loader (cdn.whissle.ai/widget.js) is on the roadmap; the iframe + SDK cover it today.
